Full-Digital Intelligent Peak-Valley Corrugated Tube Cutting Machine

For accurate pricing or product detail inquiries, please contact us—we will reply within 12 hours.

Product Description

Equipment Name: Full-Digital Intelligent Peak-Valley Corrugated Tube Cutting Machine
Equipment Model: BWGQD-400
Function: For cutting peaks and valleys of corrugated tubes and various hoses
Dimensions: L850mm×W550mm×H1100mm
Weight: Approximately 180KG
Power Supply: AC220V/2000W
Cutting Length: 20mm-999999mm
Wire Diameter Range: 7-40mm
Cutting Tolerance: ±1 peak
Cutting Process: Peak cutting
Feeding Speed: 0-3m/s
Description: BWGQD-400 is developed for peak cutting and slitting of corrugated tubes, featuring independent rotating tool post and slitting tool post. It adopts servo feeding combined with fiber positioning to enable precise cutting on peaks. Additionally, it is equipped with a separate pay-off stand pre-feeding mechanism for more stable feeding. It has a Chinese-English LCD display with full-parameterized operating system and powerful database storage function, ensuring simple and easy operation.
