Equipment Name: Semi-Automatic Coaxial Cable Stripping Machine
Equipment Model: TZBX-5806
Function: For stripping coaxial cables
Display Interface: Chinese LCD (95mm×50mm)
Working Power Supply: AC220V/110V 50/60HZ
Power: 400W
Stripping Length: 0.1mm-56mm
Overall Dimensions: 587×184×279mm
Stripping Length Setting Unit: 0.01mm
Weight: 22kg
Cutting Wire Diameter Range: Ø0.8-Ø7.0mm
Driving Method: DC servo motor / TBI ball screw
Cutting Depth Setting Unit: 0.01mm
Maximum Stripping Layers: 9 layers
Cutter Material: Imported tungsten steel (Kennametal or Fuji)
Wire Guard Material: ASSAB high-speed steel
Working Environment: -5—45°C, dry and vibration-free workbench
Storage Capacity: 99 sets of processing parameter data
Production Efficiency: 800-1100pcs/h
