New Energy Cable Cutting and Stripping Machine

Equipment Name: New Energy Cable Cutting and Stripping Machine

Equipment Model: CX-12002400

Function: Mainly applicable to various coaxial cables in the automotive industry, charging pile cables, etc.

Processing Range: 10-120mm²

Front End: Full stripping 0-100mm

Rear End: Full stripping/semi-stripping 0-160mm

Semi-stripping: 0-240mm

Full Stripping: 160-240mm (special conduit required)

Power Supply: AC380V, 3P+N+PE 50/60HZ

Power: 8kw

Air Supply: 0.6-0.8MPa

Overall Dimensions: L2200×W840×H1680mm

Additional Description: Equipped with rotating cutter heads for rotary cutting and V-shaped blades for cutting and stripping. The two cutter heads work in coordination to achieve flat cuts without damaging conductors. It can process various types and diameters of cables within the entire range without replacing blades. A data port is reserved for connecting auxiliary equipment (such as inkjet printing, MES system data collection, etc.).
