Automatic Computerized Wire Stripping Machine (Belt-Type Sheathed Wire Model)

Equipment Name: Automatic Computerized Wire Stripping Machine (Belt-Type Sheathed Wire Model)

Equipment Model: CX-1203000

Function: All-in-one machine for stripping the outer sheath and inner core of lamp wires, power cords, flat power cords, and USB data cables

Overall Dimensions: 680mm × 560mm × 480mm

Weight: 90kg

Data Storage: 99 groups

Power Supply: AC175V-250V 50/60HZ

Power: 500W-1100W

Cutting Length: 1mm – 99999mm

Stripping Length: Stripping head: 0－300mm; Stripping tail: 0－100mm

Maximum Wire Diameter: Power wire outer diameter (OD): 1-12mm

Suitable Wires: Multi-core sheathed wires, rubber wires and other power cables (integrated inner and outer stripping)

Conduit Diameter: Ф4mm—Ф12mm

Wheel Lifting Method: Motor-driven wheel lifting, pressure adjusted via touch screen CNC

Driving Method: 16-wheel simultaneous drive with belt feeding, servo motor + stepper motor

Stripping Capacity per Hour: 400—1000 pieces (varies according to actual wire type)

Pulse Equivalent: Error within 0.05mm per meter of wire

Blade Motor Precision: Silent hybrid stepper motor, 0.1mm per step

Additional Functions: Automatic wire feeding, automatic wire outlet, and timed start

Additional Description: Equipped with the latest 64-bit intelligent control system, Chinese-English switchable LCD display, and touch screen operation. Can store 100 sets of data for instant recall, featuring high efficiency and convenience. High-end configuration with servo screw slide tool rest ensures high precision, zero length error, and high output.
