Automatic Double-End Number Tube Threading Machine (U-Type)

For accurate pricing or product detail inquiries, please contact us—we will reply within 12 hours.

Product Description

Equipment Name: Automatic Double-End Number Tube Threading Machine (U-Type)
Equipment Model: QZDHMG-251006030
Function: Fixed-length cutting, single/double-end stripping, single/double-end crimping, tube cutting and printing, double-end number tube threading, double-end positioning heat shrinking
Capacity Efficiency: 2100pcs/h (when L=500mm)
Processing Wire Diameter: 0.3-2.5mm²
Stripping Length: 0-10mm
Crimping Capacity: 2T
Wire Cutting Length: 300-9999mm
Cutting Accuracy: ＜100mm±0.5mm; ＞100mm±1mm
Marking Method: UV laser (no consumables required)
Casing Specifications: Length 10-30mm; round tube Φ1-Φ6
Equipment Weight: 680kg
Dimensions: L2800×W700×H1860mm
Power and Air Supply: 220V 50/60Hz; 0.6-0.8Mpa
Operation Method: Interactive touch screen
