Semi-Automatic Dual-Wire Threading, Stripping and Crimping Integrated Machine

For accurate pricing or product detail inquiries, please contact us—we will reply within 12 hours.

Product Description

Equipment Name: Semi-Automatic Dual-Wire Threading, Stripping and Crimping Integrated Machine
Equipment Model: P-12
Function Modules: Integrated forming of dual-wire plug threading, stripping and crimping
Features: Tool-free changeover for waterproof plugs, convenient and efficient without interruption; Short cycle time and high efficiency; Capable of producing products with or without plugs, high cost performance
Stripping Method: Pneumatic
Cycle Time: 3.0-3.5(s)
Applicable Wire Diameter: 0.15-3mm
Stripping Length: 2.5-8mm
Sheath Stripping Length: >25mm when threading plugs
Waterproof Plug Size: Diameter 8mm, length 8mm
Crimping Tonnage: 2T
Press Stroke: 30 or 40mm
Changeover Components: Needle-tube-claw, track (within a certain wire diameter range)
Options: Operation host – industrial PC, networking, pressure monitoring, scanner, foot switch
Mold: Changeover time within 300s
Auxiliary Configuration: Active paper winder and material tape cutter
